USED 2004 STENNER VHF-36

-Precision vertical rip saw with 36" diameter handwheel that can accommodate 4" wide blades.
-Solid handwheel with domed surface for blade guidance.
-Feed using 3 pairs of individually motorized rollers on each side of the blade.
-Variable speed hydraulic drive system.
-High precision drive system for centered cutting for already moulded product, also ordinary cutting of various sizes.
-Manual adjustment of the dimensions to be slit.
-Easy-to-replace phenolic blade guide that requires no adjustment.-Blade change from the back of the machine.
-Steering wheel housing with safety switch. The engine cannot be started if the doors are open.
-Ducting and 0.6" (150 mm) suction opening integrated into the base.-The blade motor is equipped with a direct current (DC) brake.
-Pneumatic blade tensioning
-Steering wheel diameter: 36" (915 mm)
-Maximum cutting width : 12" (305 mm)
-Maximum cutting height : 16" (305 mm)
-Tilt of the frame and plank: 0? to 45?
-Dimensions of the planks: 19` 6" x 4" (5944 x 100 mm)
-Kerf dimension: 0.075" to 0.085" (1.9 to 2.2 mm)
-Main Motor: 40 HP (30 kW)
-Feed motors per hydraulic unit: 7.5 HP (5.5 kW)
-Vitesse d?avance : o a 200 pi/min (0 a 60 m/min)
-Working Height: 33.5" (850 mm)
-Suction Requirement: 980 CFM (1665 m3/hr)
-Approximate weight: 5280 lbs. (2400 kg)
-Floor space required (approx.): 40" X 98" (1010 x 2474 mm)
