USED 2012 ACCU SYSTEM H 49 DRILL AND DOWEL 2012

Horizontal bore and dowel
49" wide worktable of 1/2" thick machined aluminum
to ensure a true and reliable reference point
1 HP 18,000 RPM single spindle drill
Cycle time of approx. 1-1/2 seconds for each bore
glue and dowel insertion when the holes are spaced at 64 mm intervals
(4) quick adjust vertical clamps
Adjustable back fence
1/2" min. material thickness
Glue inserter with water or glue capability
"Direct Reject System" dowel inserter
8 mm dia. vibratory dowel bowl
PC operator interface with 12" touchscreen
2 work zones allowing for pendulum processing
The H-49`s operator interface has been designed to allow
for quick programming at the machine
Typically your operator can create and activate a
new program in less than one minute
