USED RADLEY ENGINEEING LTD 57 Litre

United Kingdom
Since 1932, Perry has been buying and selling high quality used process equipment for the chemical, pharmaceutical, food, plastics and paper industries.
Overview
Stainless Steel Tanks

Used Radley Engineering LTD approximately 57 litre stainless steel mixing vessel. Vessel measures 500mm diameter x 600m straight side. Rated 6bar - full vacuum design pressure with a design temperature of 0-100°c. Unit has a clamped dished top and welded dished bottom. Unit includes an off-centre bottom entry rotor with 0.25kW Bonfiglioli 3-motor operating at 2700rpm. Unit is mounted on a stainless steel frame with wheels. Frame measures 800mm diameter x 1300mm straight side.

Specs
Capacity
15 gal
57 L
Diameter
1.64'
499.87 mm
Height
1.97'
600.46 mm
Type of stainless
Unknown
Unknown
Type Of Heads
clamped dished top and welded dished bottom
clamped dished top and welded dished bottom
Vertical/Horizontal
Vertical
Vertical
Legs/Lugs/Skirt
stainless steel frame with wheels
stainless steel frame with wheels
Dimensions
Dimensions: 800mm diameter x 1300mm straight side
Dimensions: 800mm diameter x 1300mm straight side
