410 Litre 316 Stainless Steel Vertical Mixing Vessel
Overview
Stock #:
L1591-12
Description
Used Bibby approximately 410 litre 316 stainless steel vertical mixing vessel. Unit measures approximarely 650mm tan to tan x 900mm diameter. Unit has welded dished top and bottom heads. Internal rated 3.43 bar/full vacuum design pressure at 100 deg.c. Unit has top entry off-site stainless steel agitator driven by Lightnin model LS25A air operated drive. Unit is mounted on (3) stainless steel legs.
Specifications
| Capacity | 108.2 gal | 409.7 L |
|---|---|---|
| Diameter | 2.95' | 899.16 mm |
| Height | 2.13' | 649.22 mm |
| Type of stainless | 316 | 316 |
| Type Of Heads | welded dished top and bottom | welded dished top and bottom |
| Vertical/Horizontal | vertical | vertical |
| Legs/Lugs/Skirt | 3 | 3 |
| Dimensions | 650mm tan to tan x 900mm diameter | 650mm tan to tan x 900mm diameter |
