USED SMITHCO ENGINEERING 1 F 11-80-

Manufacturer Information
Manufacturer: Smithco Manufacturing
Model: 1F11-80-1
Equipment Type: Fin-Fan Cooler / Air-Cooled Heat Exchanger
Year Built: 2010
Construction: 304 Stainless Steel Tubes with Aluminum Fins
Condition: Used

Description
Available for sale is a used Smithco Model 1F11-80-1 Fin-Fan Cooler, engineered for industrial process cooling, gas cooling, liquid cooling, and heat rejection applications. This air-cooled heat exchanger utilizes a large finned tube bundle and a high-capacity COFIMCO axial fan to provide efficient heat transfer without the need for cooling water or cooling tower infrastructure.
The unit features 162 stainless steel tubes arranged in a 4-row, 2-pass configuration, each measuring approximately 11 feet long. The bundle utilizes L-tension aluminum fins to maximize heat transfer surface area and cooling efficiency.
Airflow is provided by a 7-foot diameter COFIMCO fan driven by a 10 HP motor, delivering approximately 62,000 ACFM. The fan incorporates adjustable-pitch aluminum blades, allowing airflow optimization for varying operating conditions.
Mounted within a painted carbon steel structure, this compact fin-fan cooler is ideal for compressor stations, gas processing plants, petrochemical facilities, refineries, power plants, and industrial manufacturing operations requiring dependable air-cooled heat exchange.

Specifications
General Information

Manufacturer: Smithco Manufacturing
Model: 1F11-80-1
Equipment Type: Fin-Fan Cooler
Year Built: 2010
Condition: Used

Overall Dimensions

Length: Approximately 12.5 Feet
Width: Approximately 8.0 Feet
Height: Approximately 7.0 Feet

Weight

Approximate Weight: 6,000 Pounds

Heat Exchanger Bundle
Tube Configuration

Quantity: 162 Tubes
Tube Diameter: 1 Inch
Tube Material: 304 Stainless Steel
Tube Length: 11 Feet
Configuration: 4 Rows
Pass Arrangement: 2-Pass

Fin Design

Fin Type: L-Tension Aluminum
High Efficiency Heat Transfer Surface

Process Connections
Inlet

10 Inch
ANSI 300# Flange

Outlet

10 Inch
ANSI 300# Flange

Pressure & Temperature Ratings
Maximum Working Pressure

50 PSIG

Temperature Range

-20°F to 350°F

Fan System
Fan Manufacturer

COFIMCO

Fan Model

2134-4-24L/B3T

Fan Quantity

One (1)

Fan Diameter

7 Feet

Blade Configuration

Four (4) Aluminum Blades

Blade Adjustment

Adjustable Pitch
10° Blade Angle

Airflow Capacity

62,000 ACFM

Drive System
Fan Motor

10 HP
460 Volt
3 Phase
60 Hertz

Drive Type

Belt Driven Speed Reducer

Structural Construction

Painted Carbon Steel Frame
Outdoor Industrial Service Design
Air-Cooled Operation
Heavy-Duty Support Structure

Applications

Natural gas cooling
Process gas cooling
Compressor aftercooling
Lube oil cooling
Industrial process cooling
Petrochemical processing
Refinery operations
Power generation facilities
Pipeline compressor stations
Utility cooling systems
Chemical processing
Manufacturing operations

Products This Equipment Would Be Used For

Natural gas
Process gases
Compressor discharge gas
Lube oil
Hydraulic fluids
Industrial liquids
Petrochemical products
Utility fluids
Process streams
Industrial lubricants
Cooling circuits
Energy production systems

Frequently Asked Questions

What type of equipment is the Smithco 1F11-80-1?
It is an air-cooled fin-fan heat exchanger designed for industrial process cooling applications.

How many tubes are installed in the bundle?
The bundle contains 162 stainless steel tubes.

What material are the tubes made from?
The tubes are constructed from 304 stainless steel.

What type of fin system is used?
The unit utilizes L-tension aluminum fins to maximize heat transfer efficiency.

What size are the process connections?
The exchanger features 10-inch ANSI 300-pound inlet and outlet connections.

What is the maximum pressure rating?
The unit is rated for 50 PSIG operation.

What temperature range can the exchanger handle?
The exchanger is rated from -20°F to 350°F.

What is the airflow capacity of the fan system?
The COFIMCO fan delivers approximately 62,000 ACFM.

What motor drives the fan?
The fan is powered by a 10 HP, 460V, 3-phase motor.

What industries commonly use fin-fan coolers?
Natural gas processing, petrochemical plants, compressor stations, refineries, power generation facilities, and industrial manufacturing operations commonly utilize fin-fan coolers.
