USED 2003 L.A.I.P. SRL 3800 L

Used vertical stainless steel storage tank by L.A.I.P. Srl (IT). Desgned in stainless steel AISI 316L (1.4404). Tank has volume 3800 l and is rated for work on pressure up to 4.5 bar at temperature range from 2 up to 156 C. Internal diameter 1446 mm x length of straight side of wall 1800 mm. Top and bottom elipsoidal. Top is pneumatically risen. Closing by clamp and ring. Tank is mounted on 4 stainless steel legs. Central bottom discharge. Three connections on discharge - two with diameter 206 mm and one with diameter 129 mm. Last time used in textile industry as a dye tank. Technical documentation included.
