1200 L Vertical Stainless Steel Silos Conical Bottom With Valve

Used vertical stainless steel silos with conical bottom. Total volume 1200 l, working volume about 1000 l. Internal diameter 1000 mm x length of straight side of wall 1335 mm. Silos has conical bottom with central outlet diameter 150 mm, equipped with pneumatically operated slide valve by DMN , type SCPP 150 1. Silos is equipped with two sensors of level mounted on side wall. Top covered with bolted lid. Central feeding inlet has diameter 318 mm. There is also inspection manway width 500 mm. Silos is mounte on 4 lugs.
