2200 L Vertical Stainless Steel Mixing Tank With Propeller Agitator

Overview
Stock #:
U2369-2
Description

Used vertical stainless steel mixing tank with total volume about 2200 l. Tank has internal diameter 1200 mm x length of straight side of wall 2000 mm. Top open, covered with manually operated lid, equipped with stainless steel propeller agitator driven by gearbox and el motor 1.5 kW, 1420 rpm, 220-380 V, 50 hz. Bottom welded, with slightly conical shape. Central discharge main outlet, and two bottom connections/outlets. Tank is mounted on stainless steel round support. Shipping dimensions (horizontal position) L 300 cm x diameter 130 cm.

Specifications
Capacity581 gal2,199.3 L
Diameter3.94'1,200 mm
Height6.56'2,000 mm
Type of stainlessunknownunknown
Type Of Headsopen, covered with manually operated lidopen, covered with manually operated lid
Vertical/HorizontalVerticalVertical
Legs/Lugs/SkirtLegsLegs
Dimensions300cm x 130cm300cm x 130cm
