USED 2021 OKUMA GENOS M460V-5AX
Overview
Description
Used 5-axis vertical machining center. Features include 30" X, 18.11" Y/Z travel, 15,000 RPM spindle, and 660 lb max load. Equipped with spindle chiller, 300 PSI coolant thru spindle, and Renishaw RMP60 probing.
Specifications
| X | 30" | 762 mm |
|---|---|---|
| Y | 18.11" | 459.99 mm |
| Z | 18.11" | 459.99 mm |
| # Axis | 5 | 5 |
| Power | 30 hp | 22.4 kW |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 32 | 32 |
| Taper | CAT 40 Big Plus | CAT 40 Big Plus |
X-Axis Travel 30"
Y-Axis Travel 18.11"
Z-Axis Travel 18.11"
A-Axis Travel 20 To -110 Degrees
C-Axis Travel 360 Degrees
Table Surface To Spindle Nose 3.94" To 22.05"
Table Size 15.75"
Max Work Size 23.62" (Diameter) X 15.75" (Height)
Floor To Table Top 41.34"
Max Load Capacity 660 Lbs
Spindle Speed 15,000 RPM
Spindle Taper CAT 40 Big Plus
Rapid Traverse X,Y 1575 Ipm
Rapid Traverse Z 1260 Ipm
Cutting Feedrate 1260 Ipm
Spindle Motor 30/25 HP
ATC Capacity 32
Equipped With
Simultaneous 5 Axis Capability
Spindle Chiller
Coolant Thru Spindle (300 PSI)
CAT 40 Big Plus Tool Shank
Chip Conveyor
Renishaw RMP60 Probing System
