Used Wilhelm Schulz 5750 litre total capacity stainless steel vertical reactor. Internal approximately 1800mm diameter X 1686mm straight side. Has welded dished top and bottom heads. Internal rated full vacuum/6 bar design pressure at 225 DEGC. Has carbon steel external jacket 570 litre capacity rated full vacuum/6 bar design pressure at 270 DEGC. Includes 3-tier 2-blade pitched paddle agitator direct driven by 4 kW 400 volt 3/50 1435 rpm motor via Stelzer model SNR 25/06 gearbox at 64 rpm. Includes (2) wall mounted baffles. Mounted on (4) side support lugs.
| Capacity | 1,518.2 gal | 5,747.1 L |
| Type of stainless | Stainless Steel | Stainless Steel |
| Internal Pressure | 87 PSI | 6 bar |
| Internal Temperature | 437°F | 225°C |
| Jacket Pressure | 87 PSI | 6 bar |
| Diameter | 70.87" | 1,800.1 mm |
| Straight Side | 66.38" | 1,686.1 mm |
| Type Of Heads | Welded dished top and bottom | Welded dished top and bottom |
| Legs/Lugs | 4 side support lugs | 4 side support lugs |
