| X | 20.08" | 510.03 mm |
| Y | 20.08" | 510.03 mm |
| Z | 18.11" | 459.99 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 30 | 30 |
| Taper | HSK 63 | HSK 63 |
| Pallet-W | 19.69" | 500.13 mm |
| Pallet-L | 15.75" | 400.05 mm |
| # Axis | 5 | 5 |
| Control | CNC (Mazatrol 640M 5X) | CNC (Mazatrol 640M 5X) |
Rotary Table / Trunnion: 5th Axis Trunnion
Tool Magazine Capacity: 30
Number of Pallets: 1
Max Tool Diameter: 3.5 inches
Table / Pallet Size: 19.69" x 15.75 inches
Max Tool Diameter(adjacent): 4.92 inches
X-Travel: 20.08 inches
Chip-to-Chip Time: 4.5 seconds
Y-Travel: 20.08 inches
Spindle Nose to Table Top: 7.48-25.59 inches
Z-Travel: 18.11 inches
Max Tool Length: 11.81 inches
Spindle Taper Type: HSK63
Max Tool Weight: 17.6 lbs
Spindle Speed: 12,000 RPM
Max Table/Pallet Load: 661 lbs
Spindle Motor: 30 HP
Additional Machine Specs: Travels:
- A-Axis: +/-150° (-120° to +30°)
- B-Axis: 0.001°
Control Make/Model: Mazatrol 640M 5X CNC Control
Additional Control Options: Windows 2000 Operating System
High Speed Smoothing
Die Mold Package
Machine Options: Tool Presetter
30 ATC, HSK 63 , 12,000 RPM 30 HP Spindle,
Additional Control Options: Windows 2000 Operating System
High Speed Smoothing
Die Mold Package
Machine Options: Tool Presetter
