Vertical Machining Center, used, features a 30" x 16" x 20" work envelope, 30 hp power, BT-30 taper, and a 30,000 RPM spindle. Equipped with 4th and 5th axis prewire, 20-tool ATC, work lights, running software M16.02C.
| X | 30" | 762 mm |
| Y | 16" | 406.4 mm |
| Z | 20" | 508 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 30,000 RPM | 30,000 RPM |
| # ATC | 20 | 20 |
| Taper | BT-30 | BT-30 |
| Table-W | 14" | 355.6 mm |
| Table-L | 36" | 914.4 mm |
| # Axis | 3 | 3 |
| Control | CNC (HAAS) | CNC (HAAS) |
30,000 RPM Spindle
Work Lights
4th Axis Brushless Prewire
5th Axis Brushless Prewire
Software Versions M16.02C
Probing Pictured Not Include
