FMB Turbo 5-55 Barfeed – 2011
Specs
Bar Length Capacity: 500–2200 mm (19.7″–86.6″)
Maximum Bar Diameter: 55 mm (2.17″)
Minimum Bar Diameter: 5 mm (0.197″)
Feed Speed: Variable, 0–700 mm/sec
Return Speed: Up to 1000 mm/sec
Feed Force: Up to 750 N
Loading Time: Approximately 30 seconds
Power Requirement: 2.5 kW
Electrical Supply: 400V, 50 Hz standard (other voltages available)
Control Voltage: 24 VDC
Air Requirement: 6–10 bar (87–145 psi)
Air Consumption: ~17.5 L per loading cycle
Oil Capacity: 80 L
Weight: Approximately 1,500 kg (3,300 lb) without oil
Noise Level: Approximately 48 dB(A) during bar change
Equipped With
• Digital Control
• Bar diameter capacity: 5 mm to 55 mm (.196” to 2.165”)
• Automatic loading magazine — 11 linear inches of rack capacity
• Double pusher, space saving design
• Polyurethane guide channel system — noise & vibration dampening
• Quick change guide channels and pusher
• Hydrodynamic support via high volume oil flow into channels
• Bosch motion control — dependable and user friendly, allows easy bar feeder parameter changes with remote pendant
• Separate floor mounted electric cabinet isolates electronics from vibration
• Automatic remnant retraction, self centering gripper
• Outboard roller steady rest—quick adjust system and super rigid design. Mounted to base of machine to provide maximum support of bar stock and pusher
• 48 part program memory storage
All specifications and accessories are assumed to be correct but must be confirmed by the purchasing entity.
