NEW 2024 PINNACLE DV2142
Overview
Double Column Vertical Machining Center, Bridge Type Machining Center, Planer type CNC Machining Center. Fanuc Oi-MD, 10.4" LCD, AICC II, Jerk control, Semi Splash Guard, Chain type chip conveyor, 2 Screw type chip conveyors 32 ATC, Auto door for ATC, Spindle oil cooler, Heat exchanger, Coolant system, air gun and water gun, work lamp, "Z" axis BOX ways.
Specs
"X" Axis travel: 165.35"
Y" Axis travel: 82.6"
"Z" axis travel: 35.4"
Distance between Columns: 82.6"
Table size: 165" X 67"
No. of Bearing support Blocks "X"/ "Y": 16/6/6
Distance spindle nose to Table: 6.25" to 41.75"
Ball Screws / linear way size X/Y/Z: 2.75",2.16",1.96"/ 2.75", 1.7"
Spindle Taper: Cat 50
Spindle Speed: 2 speed GEARED HEAD, 8,000 RPM
Draw bar force: 4,000 lbs.
Spindle power: 20/25 H.P. 30 mins.
Optional Spindle motor: 25/30 H.P. 30 mins.
Optional speeds: 10,000 RPM #40 taper
Cat.50 10,000 RPM direct drive, w/ column ext.13.7": to 49.2"
Cat. 50 10,000 RPM Built in spindle+ Column ext. 7.8: to 43.3"
