NEW 2024 PINNACLE DV2132
Overview
Double Column Vertical Machining Center, Bridge Type Machining Center, Planer type CNC Machining Center, 5 Axis, five sided. Fanuc Oi-MD, 10.4" LCD, AICC II, Jerk control, Semi Splash guard, Chian type chip conveyor, 2 Screw type chip conveyors 32 ATC changes tools in both Vertical Spindle as well as Horizontal head, Automatic head changer and storage, Auto door for ATC, Spindle oil cooler, Heat exchanger, Coolant system, air gun and water gun, work lamp, "Z" axis BOX ways.
Specs
"X" Axis travel: 126"
Y" Axis travel: 82.6"
"Z" axis travel: 35.4"
Distance between Columns: 82.6"
Table size: 126" X 67"
No. of Bearing suppart Blocks "X"/ "Y": 12 / 6
Distance spindle nose to Table: 6.25" to 41.75"
Ball Screws / linear way size X/Y/Z: 2.75",2.16",1.96"/ 2.16", 1.7
Spindle Taper: Cat 50
Spindle Speed: 2 speed GEARED HEAD, 8,000 RPM
Draw bar force: 4,000 lbs.
Spindle power: 20/25 H.P. 30 mins.
Optional Spindle motor: 25/30 H.P. 30 mins. $ 5,500.00
Auto head Changer: and Storage unit
2 Axis positioning head, 5 degree increments: Horizontal and vertical
Automatic tool changer: Vertical and Horizontal
Data Server 2 GB & ethernet: $4,000.00
Coolant thru spindle 300 PSI: $15,900.00
Full Splash guarding, including roof: $26,000.00
Flat rack Just assembly Tool changer: $18,000.00
Work piece measurement: $ 10,800.00
Laser tool measurement: $ 10,800.00
60 Tool Auto changer: $ 18,000.00
Optional 82.6" Wide table: $9,900.00
Equipped With
50 Taper 2 speed Geared head, 32 ATC, Semi-Full splash guard, Chain type chip conveyor + cart, Auto door for ATC, Spindle oil cooler, Heat Exchanger, Transformer, Coolant system, Air gun and water gun, Work light, 2 Screw type chip conveyor, Manuals, toolbox and one year parts and labor.
