NEW 2026 PINNACLE DV 1432
Overview
Double Column Vertical Machining Center, Bridge Type Machining Center, Planer type CNC Machining Center, Gantry type Milling Machine. Spindle oil cooler, Heat exchanger, Coolant system, air gun and water gun, work lamp, "Z" axis BOX ways,
Specs
"X" Axis travel: 125.9"
Y" Axis travel: 55.1"
"Z" axis travel: 35.4"
Distance between Columns: 55.11"
Table size: 125.9" x 47.24"
Spindle center to column: 15.9"
No. of Bearing support Blocks "X"/ "Y": 12/6/6
Distance spindle nose to Table: 4.33" - 39.76
Ball Screws / linear way size X/Y/Z: 2.75",2.16",2.16"/ 2.16", 1.8"
Spindle Taper: Cat 50
Spindle Speed: 2 speed GEARED HEAD, 8,000 RPM
Draw bar force: 4,000 lbs.
Spindle power: 20/25 H.P. 30 mins.
Optional Spindle motor: 25/30 H.P. 30 mins
Optional speeds: 10,000 RPM #40 taper -5,000.00
Cat.50 10,000 RPM direct drive, w/ column ext.13.7": to 49.2"
Cat. 50 10,000 RPM Built in spindle+ Column ext. 7.8: to 43.3" = $ 36,000.00
Machine is shipped assembled on a flat rack and 1 40' HQ containers, Prices are F.O.B. Chicago, IL
Set up is included
Equipped With
Fanuc Oi-MF Control with 2 year parts and labor Warranty, 10.4" LCD, Semi-full splash guard, Chain type tool changer 32 tool, lift up chip conveyor and two Augers + cart, Auto door for ATC, Spindle oil cooler, Heat exchanger for control, Transformer, Coolant system, Air gun and wash down hose, LED work lights, Leveling bolts and Manuals
