Lymco Zentrum-110R2, a high-precision boring and milling CNC with extensive travel capacity of X 2000 Y 1600 Z 1300 mm. It features a powerful spindle motor and rapid cutting feed of 5000 mm/min, perfect for meeting high-demand manufacturing needs. A sturdy build, weighing 29,000 kg, with a loading capacity of 8,500 kg, ideal for heavy-duty operations. The machine's bigger brother the R3 offers 3m of x travel and 2m of y travel.Trust ESP Machinery Australia Pty Ltd for top-quality new machinery with the latest technology.
ZENTRUM's spindle design based on technological cooperation with Japanese developers. This feature allows the spindle to sit in the middle of the column frame (box), thus forming a box-in-box structure. Additional stability is provided by dual Y-axis ball screws. The Zentrum comes in 2 configurations 110R2 and 110R3. Specs for R2 with R3 Alternative listed.
Accuracy by design
Massive 2+4 base design, TWO box ways paired by FOUR linear along the Z axis feed provide unparalleled support for heavy cutting on different applications. Box type hardness steel guideway with anti-friction Fluorine resin and forced-lubrication been applied for large-size machine and provided for the X, and Z axis guideways, positioning are performed with excellent accuracy and smooth stick/slip-free slide movements are assured.
Table for heavy jobs
Stable movements, accurate indexing and precision positioning almost uninfluenced by the weight of the work are assured for the rotary table. On the other hand, hydrostatic slideways technology are applied for table loading over 30 tons, the highly rigid structural components, and the efficient drive system
Built for heavy duty
The stable performance for milling, drilling and boring operations on heavy workpieces of large dimensions.
| Spindle Size | 110 mm | 4.3307" |
| X-Horiz Tvl of Table | 3000 mm | 78.74" |
| Alternate X axis Zentuum 110R3 | 3000 mm | 3000 mm |
| Y-Vert Tvl of Head | 1,600 mm | 62.992" |
| Alternate Y axis Zentuum 110R3 | 2000 mm | 2000 mm |
| Spindle Tvl. | 400 mm | 15.748" |
| Quill Travel | Table stroke 1300 mm | Table stroke 1300 mm |
| Table-W | 1,400 mm | 55.118" |
| Table-L | 1,600 mm | 62.992" |
| Alternate Table size Zentuum 110R3 | 1600 x 1800 mm | 1600 x 1800 mm |
| Table Loading | 8000 kg R3 10000 kg | 8000 kg R3 10000 kg |
| Control | CNC | CNC |
| Weight | 29 Tons - 32 Tons (R3) | 29 Tons - 32 Tons (R3) |
X axis (mm) ZENTRUM-110R2 2000 mm ZENTRUM-110R3 3000 mm
Y axis (mm) 1600 ZENTRUM-110R3 2000 mm
Z axis (mm) table stroke 1300 mm ZENTRUM-110R3 1500 mm
W axis (mm) quill stroke
400 (600)
400 (600)
Table loading capacity (kg)
8,500
10,000
Table size (mm)
1400 X 1600
1600 X 1800
Max. spindle speed (rpm)
2500 (4000)
2500 (4000)
Max. spindle torque (Nm)
910
910
Rapid travel X, Y, Z, W (mm/min) 10,000/ 10,000/10 ,000/30 00 10,000/ 10,000/10 ,000/3,000
Cutting feed (mm/min)
5000
5000
Machine weight (kg)
29,000
32,000
