NEW 2023 PINNACLE DV2132, 5 FACE
Overview
Pinnacle DV 2132 5 Face Double column machining center
Double column Vertical machining center, Bridge Type machining center, Planer type CNC machining center, 5 Axis, five sided
Specs
"X" Axis travel 126"
Y" Axis travel 82.6"
"Z" axis travel 35.4"
Distance between Columns 82.6"
Table size 126" X 67"
Optional 82.6" Wide table $9,900.00
No. of Bearing suppart Blocks "X"/ "Y" 12 / 6
Distance spindle nose to Table 6.25" to 41.75"
Ball Screws / linear way size X/Y/Z 2.75",2.16",1.96"/ 2.16", 1.7
Spindle Taper Cat 50
Spindle Speed 2 speed GEARED HEAD, 8,000 RPM
Draw bar force 4,000 lbs.
Spindle power 20/25 H.P. 30 mins.
Optional Spindle motor 25/30 H.P. 30 mins. $ 5,500.00
Auto head Changer and Storage unit
2 Axis positioning head, 5 degree increments Horizontal and vertical
Automatic tool changer Vertical and Horizontal
Data Server 2 GB & ethernet $4,000.00
Coolant thru spindle 300 PSI $15,900.00
Full Splash guarding, including roof $26,000.00
Flat rack Just assembly Tool changer $18,000.00
Work piece measurement $ 10,800.00
Laser tool measurement $ 10,800.00
60 Tool Auto changer $ 18,000.00
Equipped With
Fanuc Oi-MD, 10.4" LCD, AICC II, Jerk control, Semi Splash guard, Chian type chip conveyor, 2 Screw type chip conveyors 32 ATC changes tools in both vertical spindle as well as horizontal head, Automatic head changer and storage, Auto door for ATC, Spindle oil cooler, Heat exchanger, Coolant system, air gun and water gun, work lamp, "Z" axis BOX ways,
