Featuring 41.7" x 20.1" x 25" travel, 25 HP motor, 10,000 RPM, and 24 ATC. Reliable performance with Fanuc OiMC control and through spindle coolant.
| X | 41.7" | 1,059.2 mm |
| Y | 20.1" | 510.54 mm |
| Z | 25" | 635 mm |
| Power | 20 hp | 14.9 kW |
| RPM | 10,000 RPM | 10,000 RPM |
| # ATC | 24 | 24 |
| Taper | 40 | 40 |
| Table-W | 19.7" | 500.38 mm |
| Table-L | 47.2" | 1,198.9 mm |
| # Axis | 3 | 3 |
| Control | CNC (Fanuc) | CNC (Fanuc) |
X Axis Travel: 41.7"
Y Axis Travel: 20.1"
Z Axis Travel: 25"
Rapid Rate X Axis: 1,417
IPM Rapid Rate Y Axis: 1,417 IPM
Rapid Rate Z Axis: 1,181 IPM
Table Size: 47.2" x 19.7"
Max Table Load: 1,763 LBS
Spindle Motor: 25 HP
Spindle Speed: 10,000 RPM
Spindle Taper: 40 CT
Distance from table to spindle nose: 5.9" to 30.9"
Distance from column to spindle center: 24.2"
Tool Changer: 24 ATC
Machine Dimensions: 122" x 117" x 114"
Machine Weight: 16,534 LBS
Fanuc OiMC Control
Chip Conveyor
Through Spindle Coolant
24 ATC
10,000 RPM
