YCM WV-108B Vertical Machining Center, New in 2008
| X-Axis | 44.09" | 1,119.9 mm |
| Y-Axis | 30" | 762 mm |
| Z-Axis | 27.56" | 700.02 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 10,000 RPM | 10,000 RPM |
| # ATC | 24 | 24 |
| Taper | CT50 | CT50 |
| Table-W | 32.28" | 819.91 mm |
| Table-L | 51.18" | 1,300 mm |
| # Axis | 3 | 3 |
| Control | CNC (Fanuc MXP-200i) | CNC (Fanuc MXP-200i) |
| Dimensions | 169" x 138" x 140" | 169" x 138" x 140" |
| Weight | 25,000 lbs | 25,000 lbs |
General Specifications:
Table Size: 32.28" x 51.18"
Table Capacity: 2,464 lbs
Max Distance Spindle To Tabletop: 35.43"
X-Axis Travel: 44.09"
Y-Axis Travel: 30"
Z-Axis Travel: 27.56"
Spindle Speed: 10,000 RPM
Spindle Taper: CAT 50
Main Motor: 30 HP (30 min rating)
Tool Changer Capacity: 32
X-Axis Feedrate: 393 IPM
Y-Axis Feedrate: 393 IPM
Z-Axis Feedrate: 393 IPM
X-Axis Rapid Traverse Rate: 944 IPM
Y-Axis Rapid Traverse Rate: 944 IPM
Z-Axis Rapid Traverse Rate: 709 IPM
Fanuc MXP 200i CNC Control
Chiller Unit
Coolant Through Spindle
Chip Conveyor
