Capacity: 1/4"; Length: 12’; Knife Size: 1” x 3” x 148”; Number of Holddowns: 19; Holddown Tonnage: 19; Cycles per Minute ‚Äì Full Stroke: 20, Short Stroke: 46; Motor: 20 HP, Wired: 480/60/3; Approximate Dimensions: 173” x 87” x 87”; Approximate Weight: 22,000 Lbs.; Equipped with: Original Factory Paint; 36” Backgauge, (2) 2’ Front Support Arms with T-Slots, recessed Inch/Metric Scales and Disappearing Stops, (2) T-Slots in Table: Machined Front to Back with Inch/Metric Scales recessed into Table, Protractor, Power Blade Clearance Adjustment, 4’ Squaring Arm, (2) Custom Made Sheet Drop Tables: 48” x 51” x 19” and 51” x 103” x 19”, and User Manual
| Max Thickness | 0.25" | 6.35 mm |
| Length of Blade | 12' | 3.7 m |
| Hyd/Mech | Hyd | Hyd |
| Back Gauge | 36" | 914.4 mm |
| Power | 20 hp | 14.9 kW |
| SPM | 20 strokes/min. | 20 strokes/min. |
| Dimensions | 173 x 87 x 87 | 173 x 87 x 87 |
| Weight | 22000 Lbs | 22000 Lbs |
