NEW 2026 PNNACLE LV-105

Pinnacle LV-105 Vertical Machining Center

Pinnacle CNC Vertical Machining Center, CNC Milling machine Model LV-105, heavy duty Roller Way, meehanite castings, Patented Counter weight system, , Fanuc control 0.0001" bi directional positioning accuacy FULL Travel !,

Table Size 48" X20"
Table Load 1320 lbs.
X Axis Travel 40"
Y Axis Travel 22"
Z Axis Travel 22"
Spindle Nose to Table 3.9" to 26"
Spindle Taper 40 taper
Spindle Speed 10,000 RPM
Rapid on (X, Y, Z) 1417 IPM
Cutting Feedrates 393 IPM
Tool Changer Type Swing Arm
Tool Changer Capacity 24 Tools
Tool Shank Cat #40
Max Tool Diameter 4.52"
Max. Tool Weight 33 lbs.
Spindle Motor 16/20 HP
Drive Motors (X, Y, Z) 4 HP
Chip Conveyor Type screw 2 total
Coolant Tank capacity 300L, 80 Gallons
Power Required 20 KVA
Air Required 6 Kg/cm2
Floor Space ( L x W x H ) 111" X 86" X 116"
Machine Weight 12,540 lbs.
draw bar force 2000 kgf/ 4,400 lbs.
Spindle chiller INCLUDED
12,000 RPM Spindle Belt drive $ 7,600.00
Chain Type Chip conveyor (Lift Up) $ 2,000.00
Coolant through Spindle 300PSI $ 6,800.00
Swing Arm 24 ATC $7,000.00
Delivery ARO 30 to 90days
Terms ... 30% Down 60% At Dock Bal 10 Days After Delivery

Fanuc Oi-MF control w/ Color CRT, AICC II (200 blocks), Fanuc function Jerk control and Manual Guide 0i., Belt drive 10,000RPM Spindle with 40 taper, Coolant system, Work light, Auto lube, Operation status light, spindle air blast, cutting air blow, Spindle oil cooler, Flushing system, Full splash gaurd, 20 Tool Armless type tool changer.
Machine2 year Warranty Parts and labor, control 2 years parts and labor
