NEW HWACHEON Hi-Tech 450CL YSMC

Specifications (subject to buyer verification):
Capacity
Swing Over Bed: Ø700 mm
Swing Over Saddle: Ø550 mm
Max Cutting Diameter: Ø420 mm
Standard Cutting Diameter: Ø254 mm
Max Cutting Length: 1,150 mm
Chuck Size (Main): 15"
Chuck Size (Sub): 8"

Spindle
Type of Spindle Nose: A2-11
Max Spindle Speed: 1,800 RPM
Through Spindle Hole Diameter: Ø132 mm
Max Bar Size: Ø116 mm
Spindle Bearing Inner Diameter: Ø180 mm
Spindle Motor: 22 / 18.5 (Opt: 26 / 22)

Sub-Spindle (Opt)
Type of Spindle Nose: A2-6
Max Sub-Spindle Speed: 4,000 RPM
Through Spindle Hole Diameter: Ø62 mm
Max Bar Size: Ø51
Spindle Bearing Inner Diameter: Ø100 mm
Spindle Motor: 7.5 / 5.5 (Opt: 11 / 7.5) kW

Turret
Number of Tool Station: 12
Tool Size (Out Dia x Boring bar size): □25 × Ø50 mm
Turret Indexing Time: 0.25 sec/step

Axes
Rapid Traverse (X / Z / Y / B): 20 / 24 / 10 / 16
Max. Stroke (X / Z / Y / B): 280 / 790 / 120 / 670
Feed Motor (X / Z / Y / B): 4.0 / 4.0 / 4.0 / 1.6

Tailstock
Tailstock Stroke: 1,250 mm
Cylinder Diameter: Ø100 mm
Quill Stroke: 120 mm
Quill Taper: #5 MT

Turnmill (Opt.)
Spindle Motor: 3.7 / 2.2 kW
Max Spindle Speed: 5,000 RPM
Max Drill/Tap Size (Endmill / Collet size: Ø20 / ER 32
Min. Index Angle: 0.0001 deg

Tank Capacity
Lubrication: 12 ℓ
Hydraulic: 50 ℓ
Coolant: 190 ℓ

Power Sources
Electrical Power Supply: 50kVA

Machine Size
Height: 2,205 mm
Floor Space (L x W): 4,100 x 2,045 mm
Weight: 8,400 Kgf

Equipped With (subject to buyer verification):
Fanuc 0iTF Plus Controller
Hydraulic Chuck 15”
Air Blower
Tool Presetter
Chip Conveyor Side Discharge Hinge Belt
One Axial Holder
One Radial Holder
Upgrade Subspindle to 10” Chuck
Upgrade main spindle motor
Oil skimmer
Upgrade mill turn motor
Coolant gun
Arbitrary speed threading (if not standard)
Thread repair function (if not standard)
Chuck pressure check switch
Coolant blow
High pressure pump 15 bar
Air Gun
(2) OD Toolholders
(1) U Drill Holder
