| Swing | 34" | 863.6 mm |
| Centers | 120" | 3,048 mm |
| Spindle Bore | 4.125" | 104.77 mm |
| Power | 20 hp | 14.9 kW |
| RPM | 800 RPM | 800 RPM |
| Swing Over Cross Slide | 25" | 635 mm |
Specifications (subject to buyer verification):
20HP 3PH 220V 60HZ Motor, CSA Elec.
Swing 870mm x 3000mm DBC
Spindle bore: 104mm
Spindle nose: D1-11
Spindle speed: 8-800rpm
Equipped with (subject to buyer verification):
Standard Accessories:
Set of driving belts and change gears
Ground steel center MT#6
Spindle sleeve ASA 450*MT#6
4 way tool post
Tool box with wrenches, spanner and touch up paint
Instruction manual
Auto longitudinal 5 steps stop
Coolant system complete with pump, piping
Chuck Guard
With Gap Bed
HR LED WORK LIGHT
D-MULTIFIX TOOL POST – DA set
HR 3000 TOOLPOST GUARD
HR3000 FULL LENGTH SPLASH GUARD
HR E STOP 3RD - HR E STOP 3RD
Options:
7.9” Follow Rest – USD $1510ea
11.9” Steady Rest – USD $2262
19.7” Steady Rest – USD $2770
23.5” Steady Rest – USD $4150
Micrometer carriage stop – USD $385
Turret carriage stop – USD $305
Auto 5 steps stop – USD $1060
Drilling attachment – USD $1540
Coolant – USD $2330
Taper attachment – USD $3705
Live center MT#6 – USD $2600
Cross slide +200mm – USD $1750
Cutting attachment – USD $1080ea
Hydraulic brake system – USD $4440
Boring bar holder – USD $4920
2843-2D11 CHUCK ( what Size of chuck OD?)
