NEW HWACHEON Hi-Tech 650 BXL YMC

Specifications (subject to buyer verification):
Swing over bed: Ø940mm
Swing over saddle: Ø620mm
Max. Cutting Diameter: Ø600mm
Standard Cutting Diameter: Ø274.7mm
Max. Cutting Length: 3,100mm
Chuck Size (Main): Chuck Size (Main): 21"
Type of Spindle Nose: A2-15
Max. Spindle Speed: 1,500 RPM
Through Spindle Hole Diameter: Ø185mm
Max. Bar Size: Ø165mm
Spindle Bearing Inner Diameter: Ø240mm
Spindle Motor: 45 / 37 (Opt.: 60 / 50)
Spindle Torque: 4,108Nm
Number Tool Station: 12
Tool Size (Out Dia. x Boring bar size): □32 × Ø60
Turret Indexing Time sec/step: Index: 1.8 Rotation: 0.5
Rapid Traverse (X / Z / Y): 20 / 10 / 10 m/min
Max. Stroke (X / Z / Y): 360 / 3,300 / ±80 mm
Feed Motor (X / Z / Y): 4 / 7 / 4 kW
Tailstock Stroke: 3,250mm
Cylinder Dia.: Ø120mm
Quill Stroke: 150mm
Quill Taper: #5
Spindle Motor: 7.5 / 5.5 (Opt.: 11 / 7.5)
Max. Spindle Speed: 3,000 RPM
Max. Drill/Tap Size (Endmill / Collet size): Ø32 / ER 40mm
Min. Index Angle: 0.0001 deg.
Tool Holder: BMT 75
Lubrication Tank Capacity: 12L
Hydraulic Tank Capacity: 50L
Coolant Tank Capacity: 370L
Electrical Power Supply: 75kVA
Floor Space (L x W): 8,430 x 2,160mm
Height: 2,600mm
Weight: 16,400 kg

Equipped With (subject to buyer verification):
Fanuc 0i-TF Plus Controller
Spindle motor upgrade with ZF gearbox
Hwacheon chip conveyor
One (1) Axial and one (1) Radial turnmill holder
Turnmill spindle motor upgrate
Air blower
Air gun
Coolant gun
Arbitrary speed threading
Thread repair function
Steady rest base (body program)
Steady rest bracket
Chuck pressure check switch
Oil Skimmer
U-Drill holder
Tool presetter
