NEW HWACHEON HI-TECH 230BL YSMC

Specifications (subject to buyer verification):
Capacity
Swing over bed: Ø750 mm
Max Cutting Diameter: Ø400 mm
Standard Cutting Diameter: Ø277 mm
Max Cutting Length: 560 mm
Chuck Size (Main): 10"
Chuck Size (Sub): 6"

Spindle
Type of Spindle Nose: A2-8
Max Spindle Speed: 3,500 RPM
Through Spindle Hole Diameter: Ø91 mm
Max Bar Size: Ø81 mm
Spindle Bearing Inner Diameter: Ø140 mm
Spindle Motor: 18.5 / 15 kW

Sub-Spindle (Opt)
Type of Spindle Nose: A2-5
Max Sub-Spindle Speed: 5,000 RPM
Through Spindle Hole Diameter: Ø62 mm
Max Bar Size: Ø51 mm
Spindle Bearing Inner Diameter: Ø90 mm
Spindle Motor: 11 / 7.5 kW

Turret
Number of Tool Station: 12 (24 Positions Index)
Tool Size (Out Dia x Boring bar size): □25 × Ø40 mm
Turret Indexing Time: 0.344 sec/step

Axes
Rapid Traverse (X / Z / Y / B): 30 / 30 / (10) / 24 m/min
Max. Stroke (X / Z / Y / B): 240 / 700 / (120) / 640 mm
Feed Motor (X / Z / Y / B): 3.0 / 3.0 / (3.0) / 1.8 kW

Tailstock
Tailstock Stroke: 700 mm
Cylinder Diameter: Ø65 mm
Quill Taper: #5

Turnmill (Opt.):
Spindle Motor: 5.5 / 3.7 kW
Max Spindle Speed: 5,000 RPM
Max Drill/Tap Size (Endmill / Collet size): Ø20 / ER 32
Min. Index Angle: 0.0001

Tank Capacity
Lubrication: 12 ℓ
Hydraulic: 11 ℓ
Coolant: 140 ℓ
Large Capacity Coolant (Opt): 22 5ℓ

Power Sources
Electrical Power Supply: 40 kVA

Machine Size:
Height: 2,140 mm
Floor Space (L x W): 3,133 x 1,924.5 mm
Weight: 6,800 Kgf

Equipped With (subject to buyer verification):
Fanuc 0i-TF Plus ​(Opt: SIEMENS 828D)
