Integrated high capacity variable speed belt feeder.
Grease filled 4 bearing.
2 deck screenbox.
Screen walkway and access ladder.
Hydraulic folding conveyors.
Output Potential: Up to 400tph (441 US tph).
Hopper:
Capacity: 7.5m3 (9.8yds3)
Variable speed
Reject grid as standard
Capacity: 7.5m3 (9.8yds3)
Variable speed
Reject grid as standard
Feeder Conveyor
Width: 1050mm (42 In.)
Variable speed
Width: 1050mm (42 In.)
Variable speed
Power Unit:
Tier 3/Stage 3A:
CAT C4.4 ATAAC 83kW (111hp).
Tier 4F/Stage 4:
CAT C4.4 82kW (110hp).
CAT C4.4 98kW (131hp).
Fuel tank capacity: 336 L (88 US Gal)
Tier 3/Stage 3A:
CAT C4.4 ATAAC 83kW (111hp).
CAT C4.4 ATAAC 83kW (111hp).
Tier 4F/Stage 4:
CAT C4.4 82kW (110hp).
CAT C4.4 98kW (131hp).
CAT C4.4 82kW (110hp).
CAT C4.4 98kW (131hp).
Fuel tank capacity: 336 L (88 US Gal)
Main Conveyor:
Width: 1050mm (42 In.).
Hydraulically adjustable.
Width: 1050mm (42 In.).
Hydraulically adjustable.
Screenbox:
4 Bearing, 2 deck screenbox.
Size: 3.33m x 1.53m (11 Ft. x 5 Ft.).
4 Bearing, 2 deck screenbox.
Size: 3.33m x 1.53m (11 Ft. x 5 Ft.).
Tail Conveyor (Finesize):
Width: 1200mm (48 In.).
Discharge height: 3.91m (12 Ft. 10 In.).
Width: 1200mm (48 In.).
Discharge height: 3.91m (12 Ft. 10 In.).
Side Conveyor (Midsize & Oversize):
Width: 650mm (26 In.).
Discharge height: 4.49m (14 Ft. 9 In.).
Individual variable speed.
Width: 650mm (26 In.).
Discharge height: 4.49m (14 Ft. 9 In.).
Individual variable speed.
Location: Japan
