NEW 2024 PINNACLE DV2142
Overview
Pinnacle DV 2142 Double column machining center
Double column Vertical machining center, Bridge Type machining center, Planer type CNC machining center, Gantry type Milling machine., like Cincinnati, Okuma, Mori,
Specs
"X" Axis travel 165.35"
Y" Axis travel 82.6"
"Z" axis travel 35.4"
Distance between Columns 82.6"
Table size 165" X 67"
Optional 82.6" Wide table, 2 piece $9,900.00
No. of Bearing support Blocks "X"/ "Y" 16/6/6
Distance spindle nose to Table 6.25" to 41.75"
Ball Screws / linear way size X/Y/Z 2.75",2.16",1.96"/ 2.75", 1.7"
Spindle Taper Cat 50
Spindle Speed 2 speed GEARED HEAD, 8,000 RPM
Draw bar force 4,000 lbs.
Spindle power 20/25 H.P. 30 mins.
Optional Spindle motor 25/30 H.P. 30 mins. $ 5,500.00
Optional speeds 10,000 RPM #40 taper -5,000.00
Cat.50 10,000 RPM direct drive, w/ column ext.13.7" to 49.2"= $ 20,000.00
Cat. 50 10,000 RPM Built in spindle+ Column ext. 7.8 to 43.3" = $ 36,000.00
Data Server 2 GB & ethernet $4,000.00
Coolant thru spindle 300 PSI $15,900.00
Full Splash guarding, including roof $32,000.00
Coolant through spindle 1,000 PSI $19,900.00
Work piece Measurement, Marposs or Blum $12,000.00
Laser Tool length/diameter measurement $12,000.00
90 degree programmable milling head 2.5 inc. $54,000.00
Auto head changer and Auto tool changer V/H $180,000.00
Equipped With
Fanuc Oi-MF, 10.4" LCD, AICC II, Jerk control, Semi Splash guard, Chian type chip conveyor, 2 Screw type chip conveyors 32 ATC, Auto door for ATC, Spindle oil cooler, Heat exchanger, Coolant system, air gun and water gun, work lamp, "Z" axis BOX ways,
