NEW 2025 PINNACLE QV-137
Overview
Pinnacle QV-137 Fanuc Control Vertical Machining Center
4 Box ways in "Y", Heavy duty, Geared head.Like= Makino, Toyoda, Mazak, Mori, DMG, OKK, Okuma, Enshu, Doosan
#50 Taper Geared Head, Coolant thru spindle, Oil skimmer, 15" LCD, Fanuc MPG and Smart APP
Specs
Table Size 59" X 27.55
Table Load 3,300 lbs.
X Axis Travel 51.2"
Y Axis Travel 27.95"
Z Axis Travel 24"
Spindle Nose to Table 4" - 28"
Spindle Taper Cat. # 50
Spindle Speed 40-6,000 RPM
Rapid on (X, Y, Z) 787, 787 & 630 IPM
Cutting Feedrates 393 IPM
Tool Changer Type Swing Arm
Tool Changer Capacity 24 Tools
Tool Shank ISO #50
Pull Stud Coolant Thru
Max Tool Diameter 3.93"
Max. Tool Weight 44 lbs.
Spindle Motor 16/22 H.P.
Drive Motors (X, Y, Z) 2.5 Kw/ 3.35 H.P.
Chip Conveyor Type 2 screw
Coolant Capacity 350 Liters/ 92 gallons
Power Required 30 KVA
Air Required 90 psi
Floor Space ( L x W x H ) 137.4"X 121.2" X 126"
Machine Weight 22,000 lbs.
M30 Auto power off, Oil skimmer,4th axis prewire No/Charge
Draw bar force 4,400 lbs.
Coolant thru Spindle $ 9,936.00
32 ATC Cat.# 50 upgrade $ 8,900.00
Extended "Z"travel to 30.3" $ 6,900.00
Linear Scales All three axis $13,400.00
Lift up 3rd Chip conveyor $ 4,800.00
Warranty Parts and Labor 2 Years
Terms: 30% Down to Place Order - 50% by Irrevocable LC at Site Before Shipment
F.O.B. Elk Grove Village, IL
Equipped With
Fanuc Oi-MF PLUS 15" LCD screen, Pinnacle Smart APP, Fanuc manual guide i, (Pkg. A) Control w/ 15" Color CRT, AICC-II (200 blocks) look ahead,Fanuc MPG, Fanuc jerk control function & Manual guide Oi., 4th Axis pre wire, 2 Chip augers, Coolant System , Prep for CTS, Work light, Auto Lube, Spindle air blast, Part air blow, Coolant flush system, Spindle oil Cooler, Spindle cartridge cooling, 50 Taper swing arm ATC, Geared head, 6,000 RPM, oil Skimmer, Warranty Parts and labor 2 year control & machine
