USED LINDE HYDRAULICS HMV 280 02

Linde HMV 280 02 Hydraulic Motor
Quantity: 3 Units
Make: Linde Hydraulics
Model: HMV 280 02
Type: Hydraulic Motor
Style: Variable Displacement Motor for Closed and Open Loop Operation
Condition: 2 Unused, 1 Used for Testing
 Displacement:
Maximum V: 281.9cc/rev
Minimum V: 93cc/rev
Maximum V: 281.9cc/rev
Minimum V: 93cc/rev
Speed:
Max Operating Speed at Vmax: 2400 RPM
Max Speed at Vmax: 2700 RPM
Max Operating Speed at Vmin: 2900 RPM
Max Speed at Vmin: 3200 RPM
Max Operating Speed at Vmax: 2400 RPM
Max Speed at Vmax: 2700 RPM
Max Operating Speed at Vmin: 2900 RPM
Max Speed at Vmin: 3200 RPM
Pressure:
Nominal Pressure: 450 bar
Max Pressure: 500 bar
Permissible Housing Pressure: 2.5 bar
Nominal Pressure: 450 bar
Max Pressure: 500 bar
Permissible Housing Pressure: 2.5 bar
Torque: 1929 Nm
Corner Power (Theoretical): 586kW
Permissible Shaft Loads - Axial Input/Output Force: 2000N
Location: Western Canada
