USED TECHNICAL SYSTEMS 30AOLM46-PTFC

Technical Systems 30AOLM46-PTFC Chiller
Make: Technical Systems
Model: 30AOLM46-PTFC
Condition: Used, Reported in Excellent Condition with Very Little Use
Design Conditions: Ambient 95°F DB
Solution: 40% EG
Refrigerant: R-410a
Heat Exchanger Design:
Capacity: 60 Total Tons Heat Transfer at Conditions Below
Economizer: Full Capacity @ 28°F Ambient
Primary Chiller Side:
Solution: 40% EG
Entering Fluid Temp: 72°F
Supply Fluid Temp: 62°F
Flow Rate: 164 GPM
Secondary Process Side
Solution: Water
Entering Fluid Temp: 74°F
Supply Fluid Temp: 68°F
Flow Rate: 238 GPM
Capacity: 60 Total Tons Heat Transfer at Conditions Below
Economizer: Full Capacity @ 28°F Ambient
Primary Chiller Side:
Solution: 40% EG
Entering Fluid Temp: 72°F
Supply Fluid Temp: 62°F
Flow Rate: 164 GPM
Solution: 40% EG
Entering Fluid Temp: 72°F
Supply Fluid Temp: 62°F
Flow Rate: 164 GPM
Secondary Process Side
Solution: Water
Entering Fluid Temp: 74°F
Supply Fluid Temp: 68°F
Flow Rate: 238 GPM
Solution: Water
Entering Fluid Temp: 74°F
Supply Fluid Temp: 68°F
Flow Rate: 238 GPM
Pump Performance:
Primary Side:
Internal Fluid Pressure Drop: 75 Feet (Internal includes Entire Package Chiller, Economizer, Heat Exchanger, Piping, Control Valves, Etc.)
Primary Pump Motor: 7.5HP @ 75ft TDH
Secondary Process Side:
Internal Fluid Pressure Drop: 30 Feet (Internal includes Secondary Side Pumping Trim and Heat Exchanger)
Max External Fluid Pressure Drop: 30 Feet (Estimated Process Loop Losses)
Pump Motor: 7.5HP @ 60ft TDH
Primary Side:
Internal Fluid Pressure Drop: 75 Feet (Internal includes Entire Package Chiller, Economizer, Heat Exchanger, Piping, Control Valves, Etc.)
Primary Pump Motor: 7.5HP @ 75ft TDH
Internal Fluid Pressure Drop: 75 Feet (Internal includes Entire Package Chiller, Economizer, Heat Exchanger, Piping, Control Valves, Etc.)
Primary Pump Motor: 7.5HP @ 75ft TDH
Secondary Process Side:
Internal Fluid Pressure Drop: 30 Feet (Internal includes Secondary Side Pumping Trim and Heat Exchanger)
Max External Fluid Pressure Drop: 30 Feet (Estimated Process Loop Losses)
Pump Motor: 7.5HP @ 60ft TDH
Internal Fluid Pressure Drop: 30 Feet (Internal includes Secondary Side Pumping Trim and Heat Exchanger)
Max External Fluid Pressure Drop: 30 Feet (Estimated Process Loop Losses)
Pump Motor: 7.5HP @ 60ft TDH
Electrical:
Power Supply:
Voltage: 575 Volt
Frequency: 60Hz
Phase: 3-Phase
RLA Each: 93
MCA Each: 97
SCCR: 5,000 Amps
MOCP Each: 125
Power Supply:
Voltage: 575 Volt
Frequency: 60Hz
Phase: 3-Phase
Voltage: 575 Volt
Frequency: 60Hz
Phase: 3-Phase
RLA Each: 93
MCA Each: 97
SCCR: 5,000 Amps
MOCP Each: 125
Overall Dimensions:
Length: 220in
Width 87.5in
Height: 97in
Shipping Weight: 10,258 lbs.
Operating Weight: 10,731 lbs.
Length: 220in
Width 87.5in
Height: 97in
Shipping Weight: 10,258 lbs.
Operating Weight: 10,731 lbs.
View Spec Sheet Below
Location: Western Canada
