This model is in stock, but availability is limited based on remaining inventory.
| Tonnage | 110 T | 99.79 t |
| Angle (L1) | 6" | 152.4 mm |
| Angle (L2) | 6" | 152.4 mm |
| Angle (T) | 0.5" | 12.7 mm |
| Power | 10 hp | 10 hp |
| Throat | 20" | 508 mm |
| Stroke | 4" | 101.6 mm |
| Weight | 7800 | 7800 |
Angle Shear: 6″ x 6″ x 1/2″ – 3″ x 3″ x 3/8″ Miter (Some with Hydraulic Angle Hold Down)
Plate Shear: 24″ x 5/8″ | 16″ x 3/4″ | 12″ x 1″ (Some with Hydraulic Plate Hold Down)
Notcher: 2-1/2″ x 3-1/2″ x 1/2″
Power Requirements: 3 Phase | 220/480
-Dual-Cylinder – Dual-Operator – Two Foot Pedals
-Five fully integrated working stations
-Angle shear Optional Hydraulic Hold-Down
-Plate Shear Optional Hydraulic Hold-Down
-Angle shear with no material loss cut and four-edge blades
-Heavy-duty adjustable punch stripper with visibility window
-3 Years Parts / 1 Year Labor Warranty
