USED 2007 TBT-TIEFBOHRTECHNIK BW250S

Drilling, Milling, Tapping for heatexchanger bases and plates
Swivable A Axis + 25 to - 15 Degrees
Filtration and Coolant system 1000 L
Cip conveyor 2000 x 1200 height out put
Milling tool changer Tower Station 20 positions
Capacity ELB Drilling 3 - 35 mm
Capacity Milling 250 ccm/Min
Feed rates all axis 15.000 mm/Min X-Y-W-Z
Cutting hours ca 15.000
Large tooling package

Max. drill Ø steel: 40 mm
Drilling depth: 1500 mm
X - Travel: 2000 mm
Y - Travel: 1300 mm
Z - Travel: 1500 mm
W - Travel: 750 mm
Table load: 15000
Table size L x W / or ø: 1600 x 1200 mm
Spindle taper: HSK 63 Mk
Power on spindle: 11 kW
Speeds / ranges: 8000 Rpm
Length: 7200 mm
Width: 7800 mm
Height: 4250 mm
Weight: 23000 kg

Drilling, Milling, Tapping for heatexchanger bases and plates

Swivable A Axis + 25 to - 15 Degrees
Filtration and Coolant system 1000 L
Cip conveyor 2000 x 1200 height out put
Milling tool changer Tower Station 20 positions
Capacity ELB Drilling 3 - 35 mm
Capacity Milling 250 ccm/Min

Feed rates all axis 15.000 mm/Min X-Y-W-Z
Cutting hours ca 15.000
Large tooling package

Max. drill Ø steel: 40mm
Drilling depth: 1500mm
X - Travel: 2000mm
Y - Travel: 1300mm
Z - Travel: 1500mm
W - Travel: 750mm
Table load: 15000
Table size L x W / or ø:1600 x 1200mm
Spindle taper: HSK 63Mk
Power on spindle: 11kW
Speeds / ranges: 8000Rpm
Length: 7200mm
Width: 7800mm
Height: 4250mm
Weight: 23000kg
