Chip conveyor
SMW 315 3 chuck
2 x Radial live tooling holders
2 x Axial live tooling holders
Spindle bore 80 mm
BMT-Tooling system
Tool measuring probe
Spindle hours 6960 / 6270 Running hours
| Swing | 470 mm | 18.504" |
| Machining Length | 1,065 mm | 41.929" |
| # Axis | 2 | 2 |
| Power | 7.1 kW | 9.5 hp |
| Max RPM | 6,000 RPM | 6,000 RPM |
| Turning Dia | 470 mm | 18.504" |
| Weight | 8800 (LBS) | 8800 (LBS) |
Max. turning Ø: 470 mm
X-Axis: 260 mm
Z-Axis: 1065 mm
Spindle bore: 80 mm
Speedrange: 4200 Rpm
Spindle power: 30 kW
ATC / revolver: 12 BMT Tool system
Speed live tools: 6000 Rpm
Power live tools: 7,1 kW
Length: 3310 mm
Width: 1900 mm
Height: 1970 mm
Weight: 6100 kg
Chip conveyor
SMW 315 3 chuck
2 x Radial live tooling holders
2 x Axial live tooling holders
Spindle bore 80 mm
BMT-Tooling system
Tool measuring probe
Spindle hours 6960 / 6270 Running hours
Max. turning Ø: 470mm
X-Axis: 260mm
Z-Axis: 1065mm
Spindle bore: 80mm
Speedrange: 4200Rpm
Spindle power: 30kW
ATC / revolver: 12 BMT Tool system
Speed live tools:6000Rpm
Power live tools:7,1kW
Length: 3310mm
Width: 1900mm
Height: 1970mm
Weight: 6100kg
