Double carriage with 4 position revolver and 840D Siemens
Steady rest 200 - 1090 mm
Roller rest 860 - 1090 mm
4 chuck 1350 mm
Clamping from 200 - 1100 mm
Bed width 2000 mm
Stoke X Axis 950 mm
Stroke Z Axis 14900 mm
| Swing | 1,400 mm | 55.118" |
| Machining Length | 13,000 mm | 511.81" |
| Power | 129 kW | 173 hp |
| Max RPM | 20,000 RPM | 20,000 RPM |
| Turning Dia | 1,400 mm | 55.118" |
Swing over bed Ø: 1400 mm
Swing over cross slide Ø: 1100 mm
DBC Turning Length: 13000 mm
Spindle power: 129 kW
Workpiece weight: 20000
Speeds / ranges: 1 - 300 Rpm
Feed rate X-Axis: 4500 mm/min.
Feed rate Z-Axis: 4500 mm/min.
Length: 20000 mm
Width: 3380 mm
Height: 2200 mm
Weight: 100000 kg
Double carriage with 4 position revolver and 840D Siemens
Steady rest 200 - 1090 mm
Roller rest 860 - 1090 mm
4 chuck 1350 mm
Clamping from 200 - 1100 mm
Bed width 2000 mm
Stoke X Axis 950 mm
Stroke Z Axis 14900 mm
Swing over bed Ø: 1400mm
Swing over cross slide Ø:1100mm
DBC Turning Length: 13000mm
Spindle power: 129kW
Workpiece weight: 20000
Speeds / ranges: 1 - 300Rpm
Feed rate X-Axis: 4500mm/min.
Feed rate Z-Axis: 4500mm/min.
Length: 20000mm
Width: 3380mm
Height: 2200mm
Weight: 100000kg
