Rolling width: 3050mm
Rolling thickness 3x toproll Ø:60mm
Rolling thickness 5x toproll Ø:70mm
Rolling thickness prebending: 50mm
Top Roll Ø: 630mm
Bottom Roll Ø: 600mm
Side roll Ø: 500mm
Number of rolls: 4
Rolling speed: 0 - 5
Adjustiment lower roll: 200mm/min.
Adjustment side rolls: 200mm/min.
Number of driven rolls: 2
Power: 120kW
Length: 5790mm
Width: 4200mm
Height: 4200mm
Weight: 85000kg
www.mach4metal.com
| Length of Rolls | 3,050 mm | 10.01' |
| (Init/Dbl Pinch or Pyramid) | DBL PINCH | DBL PINCH |
| Max Thickness | 60 mm | 2.3622" |
| # Rolls | 4 | 4 |
| Hyd/Mech | Hyd | Hyd |
| Roll Diameter | 630 mm | 24.803" |
Rolling width: 3050 mm
Rolling thickness 3x toproll Ø: 60 mm
Rolling thickness 5x toproll Ø: 70 mm
Rolling thickness prebending: 50 mm
Top Roll Ø: 630 mm
Bottom Roll Ø: 600 mm
Side roll Ø: 500 mm
Number of rolls: 4
Rolling speed: 0 - 5
Adjustiment lower roll: 200 mm/min.
Adjustment side rolls: 200 mm/min.
Number of driven rolls: 2
Power: 120 kW
Length: 5790 mm
Width: 4200 mm
Height: 4200 mm
Weight: 85000 kg
Rolling width: 3050mm
Rolling thickness 3x toproll Ø:60mm
Rolling thickness 5x toproll Ø:70mm
Rolling thickness prebending: 50mm
Top Roll Ø: 630mm
Bottom Roll Ø: 600mm
Side roll Ø: 500mm
Number of rolls: 4
Rolling speed: 0 - 5
Adjustiment lower roll: 200mm/min.
Adjustment side rolls: 200mm/min.
Number of driven rolls: 2
Power: 120kW
Length: 5790mm
Width: 4200mm
Height: 4200mm
Weight: 85000kg
