OKK 1250 HM Horizontal Machining Center with 49.1" pallets, CAT 50, 12,000RPM
OKK (NIDEC OKK CORPORATION) is a Japanese machine tool manufacturer with a history spanning over a century. Founded in 1915, it began by producing centrifugal pumps and later expanded into machine tools. Currently, it's a leading provider of high-performance machine tools, particularly known for its heavy-duty cutting capabilities and high rigidity. The company emphasizes quality control, producing all key components in-house.
| X | 66.93" | 1,700 mm |
| Y | 55" | 1,397 mm |
| Z | 48.82" | 1,240 mm |
| Power | 50 hp | 37.3 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 60 | 60 |
| Taper | #50 | #50 |
| Pallet-W | 49.21" | 1,249.9 mm |
| Pallet-L | 49.21" | 1,249.9 mm |
| # Axis | 3 | 3 |
| Control | CNC (FANUC 31i) | CNC (FANUC 31i) |
| Weight | 72,000 pounds | 72,000 pounds |
Model HM1250S
Brand OKK
Condition Used
Year 2012
SPECIFICATIONS
CNC Control yes
Type of CNC Control Fanuc 31i—Model A5
# Axis 4
Pallet-W 49.21 inches
Pallet-L 49.21 inches
Pallet Capacity 11023 ounces
X 66.93 inches
Y 55.12 inches
Z 48.82 inches
Spindle Speed 35 - 12,000 RPM
Spindle Taper CAT 50
Main Motor 40
Tool Changer Capacity 60
Coolant Through Spindle yes
Power 40 horsepower
# ATC 60
Weight 72000 pounds
Fanuc 31i—Model A5 CNC Control.
High Pressure (1,000 psi) Coolant through the spindle.
(2) 49.21” X 49.21” Drilled and tapped pallets.
Renishaw Probe.
Transformer.
Coolant system with Chip Conveyor.
