| Swing | 1,500 mm | 59.055" |
| Centers | 13,500 mm | 531.5" |
| Spindle Bore | 740 mm | 29.134" |
| Power | 37 kW | 49.6 hp |
| RPM | 300 RPM | 300 RPM |
| Control | CNC (Fanuc) | CNC (Fanuc) |
Swing over bed : 1500
Hole Thru the Spindle: 29”
Swing over saddle : 1100
Distance between Centers on Right Side of the Headstock: 13,500mm (532”)
Distance between Centers on Left Side of the Headstock: 1,450mm (57”)
The Load capacity between centers : 10000Kg
Hole through spindle : 740mm (29”)
Spindle motor : 37Kw
Spindle rotating speed : 5 ~ 300 RPM
(2) Carriages with individual CNC controls
(2) Tailstocks
(2) Fanuc 0T CNC Controls
