| X | 19.69" | 500.13 mm |
| Y | 16.93" | 430.02 mm |
| Z | 16.54" | 420.12 mm |
| Power | 13.4 hp | 10 kW |
| RPM | 30,000 RPM | 30,000 RPM |
| # ATC | 20 | 20 |
| Taper | HSK E40 | HSK E40 |
| Table-W | 15.75" | 400.05 mm |
| Table-L | 27.56" | 700.02 mm |
| # Axis | 3 | 3 |
| Control | CNC (• Fanuc 0i-MF Plus Controller) | CNC (• Fanuc 0i-MF Plus Controller) |
| Dimensions | 65"x102"x98" | 65"x102"x98" |
| Weight | 6445 lbs | 6445 lbs |
Standard accessories:
1. Rigid tapping. 9. Work lamp.
2. Spindle air blast device. 10. Foundation bolts and blocks.
3. Fully enclosed splash guard. 11. Tool box with tools.
4. Heat exchanger for electrical cabinet. 12. water gun and air gun
5. Automatic lubrication system. 13. Operation and maintenance manual.
6. Spindle cooling system. 14. Ball type linear guideways on X/Y/Z axes.
7. Cooling system and coolant tank. 15. Standard voltage: 220V/3PH/60HZ
8. Coolant flushing device.
9. Work lamp
10. Foundation bolts and blocks.
11. Tool box with tools.
12. water gun and air gun
13. Operation and maintenance manual.
14. Ball type linear guideways on X/Y/Z axes.
15. Standard voltage: 220V/3PH/60HZ
Accessories added:
Telescopic cover on X/Y-axis for graphite cutting application 1 set,$2,500
Optional accessories:
1) 15000 rpm (D.D.S., 5.5/7.5 kW) (Fanuc αT-6 ) 1 set USD
2) Built-in spindle, HSK-E40-24krpm-Grease (10kW) (FANUC) 1 set
3) telescopic cover on X/Y-axis for graphite cutting application 1 set
4) Chain type chip conveyor with chip cart 1 set USD
5) Air conditioner for electric cabinet 1 set USD
6) Automatic shifting and blowing dust collector.
7) Cover of the tool magazine + automatic door 1 set USD
