NEW 2024 MINSTER P2H-160-63×33-FW

NEW Minster P2H-160-63×33-FW Precision Straight Side Press

SPECIFICATIONS

Press Specifications
Model Number........................................................   P2H-160-63×33-FW
Force × Distance off Bottom..................................   180 ton × 0.118 in
Crankshaft Extension Location...............................   Opposite Drive Side
Drive Arrangement..................................................   Flywheel
Drive Location........................................................   Left Hand Side
Lube Unit Location.................................................   Opposite Feed Side
Approximate Press Weight.....................................   67,000 lb
Shutheight Indicator Readout.................................   Inch
Shop Air Pressure, Minimum..................................   85 psi
Press Slide Specifications
Stroke Length, Speed Range...................................   2.95 in, 70 - 300 spm
Shutheight Adjustment...........................................   3.94 in
Quick Access Slide Range......................................   0.50 - 4.50 in
Area of Slide, R-L × F-B........................................   63.0 × 33.5 in
Slide Face Machining..............................................   Standard

Press Bolster Specifications
Bolster Plate Material..............................................   Steel
Bolster Plate Thickness...........................................   4.92 in
Area of Bolster, R-L × F-B.....................................   63.0 × 33.5 in
Opening in Bolster, R-L × F-B...............................   51.2 × 9.8 in
Bolster Plate Machining..........................................   Standard

Press Frame Specifications
Upright Passline Opening, F-B...............................   24.8 in
Area of Bed, R-L × F-B..........................................   63.0 × 33.5 in
Opening in Bed, R-L × F-B....................................   51.2 × 14.6 in
Bed Deflection at 67% of Die Area........................   0.0012 in/ft
Shutheight, Maximum (SDAU)..............................   17.72 in, on Bolster
Approx Clearance, Mount to Bottom of Bed.........   11.8 in
Approx. Distance Mount to Top of Bolster............   46.4 in
Approx. Distance Mount to Top of Bed.................   41.5 in
Approx. Floor Area, R-L × F-B..............................   132 × 80.0 in
Approx. Overall Area, R-L × F-B...........................   132 × 80.0 in
Approx. Overall Height, from Mount.....................   160 in
