NEW 2025 S&T DYNAMICS H350
Overview
Description
Toolink Engineering is pleased to introduce the S&T Dynamics Model H350. The H350 is a high-precision, heavy-duty CNC gear hobbing machine. It applies a high-strength structure for durability. It employs high-speed mechanisms to improve productivity, is designed for optimum usability with interactive programming and works with a variety of automation systems.
Specifications
| Max Dia. Gear | 350 mm | 13.78" |
|---|---|---|
| Horz/Vert | 'Vert' | 'Vert' |
| Control | CNC (Siemens 840 D SL) | CNC (Siemens 840 D SL) |
| Dimensions | 3340mm X 3157mm X 2947mm | 3340mm X 3157mm X 2947mm |
| Weight | 11000 kg | 11000 kg |
Max. workpiece diameter Ø350
Max. module M7
Table dia. Ø290 mm
Z-axis travel (AXIAL) 350 mm
X-axis travel (RADIAL) 270 mm
Hob swivel angle MAX±45 deg
Hob arbor taper NT NO.40
Hob diameter/length Ø190/220 mm
Hob shift travel 180 mm
Max. hob speed 1000 rpm
Tailstock stroke 380-780 mm
Z-axis rapid feed rate 10 m/min
X-axis rapid feed rate 10 m/min
Y-axis rapid feed rate (Hob shift) 1 m/min
Travel distance from table surface to hob center(Z-axis) 250-600 mm
Travel distance from table center to hob center(X-axis) 15-285 mm
Hob spindle output 14 kW
Tailstock fixation 500~2000 kgf
Workpiece fixation 0.8~6.4 ton
Number of Axes controlled by CNC 7 Axes (X, Y, Z, A, B, C, W)
CNC CONTROL SYSTEM SIEMENS 840DSL/ FANUC 18iMB
