This listing is for a USED Piranha P50 50‑Ton Ironworker. It is designed for punching, shearing, and notching mild steel. This unit is categorized as a hydraulic ironworker and includes capabilities such as 50‑ton punch force, punching capacity up to 1‑1/16 inch through 1/2‑inch mild steel, multiple shear stations, and coper/notcher functionality.
| Tonnage | 56 T | 50.802 t |
| Angle (L1) | 3" | 76.2 mm |
| Angle (L2) | 3" | 76.2 mm |
| Angle (T) | 0.375" | 9.525 mm |
| Power | 3 hp | 3 hp |
| Throat | 5" | 127 mm |
| Stroke | 3.375" | 85.725 mm |
| Dimensions | 55 X 24 X 58 | 55 X 24 X 58 |
| Weight | 1700 LBS | 1700 LBS |
Manufacturer: Piranha
Model: P50
Condition: USED
Punch Capacity: 50 tons
Punching Capacity:
1-1/16" diameter through 1/2" mild steel
13/16" diameter through 3/4" mild steel
Shear Capacity:
1" x 4" flat bar with fixed hold down
3/4" x 10" flat bar
5/8" x 15" flat bar
5" x 5" x 3/8" angle
4" x 4" x 1/2" angle with special knife
1-1/2" round bar
1" square bar
Coper/Notcher Capacity:
2-3/4" x 4" x 1/4"
Steel Rating: 60,000 PSI mild steel
Operational Notes: For trained operators only; safety procedures required
