NEW 2022 CARRIER 50TCQD14A2A6A0A0G0
Overview
Description
This listing is for a NEW Carrier WeatherMaker 50TCQD14A2A6A0A0G0. This packaged rooftop heat pump provides heating and cooling using dual refrigeration circuits with R‑410A, integrating compressor, condenser, and air handling sections in a single enclosure for commercial HVAC applications.
Specifications
| Dimensions | 116X62X59 | 116X62X59 |
|---|---|---|
| Weight | 999 | 999 |
Manufacturer: Carrier Corporation
Series: WeatherMaker
Model: 50TCQD14A2A6A0A0G0
Condition: NEW
YOM: 2022
Equipment Type: Packaged Rooftop Heat Pump
Cooling Capacity: 142,000 BTU/hr
Cooling Capacity (Tons): 12.5 Ton
Cooling Capacity (kW): 41.5
Heating Type: Heat Pump (Reverse Cycle)
Heating Capacity: 142,000 BTU/hr
Refrigerant Type: R-410A
Refrigeration Circuits: 2
Compressor Quantity: 2
Fan Type: Axial Condenser Fans
Nominal Voltage: 460 VAC
Phase: 3 Phase
Frequency: 60 Hz
Minimum Circuit Ampacity (MCA): 118 A
Maximum Overcurrent Protection: 183 A
Short Circuit Rating: 5 kA RMS Symmetrical
Control Voltage: 24 VAC
Design Pressure High Side: 650 PSIG
Design Pressure Low Side: 506 PSIG
Airflow Configuration: Horizontal Ducted Supply / Top Discharge Condenser
Cabinet Construction: Outdoor Packaged Steel Enclosure
Certification: AHRI Certified, ETL Listed
Function: Packaged heat pump system providing heating and cooling for commercial buildings
