NEW BENCHMARK IN LARGE TUBE FIBER LASER CUTTING PRODUCTIVITY
HSG TX5R designed to process tubes up to 20.08 inches in diameter
and weighing up to 4409 lbs , the TX5R excels in applications
requiring robust cutting capabilities, such as construction, aerospace,
energy, and transportation. Its advanced automation features and
cutting-edge technology ensure seamless integration into modern
production lines.
Laser Power
6-20kW
Cutting Capacity of Round Tube/Square Tube
φ1.97'' - Φ20.08'' / □1.97''×1.97'' - □20.08''×20.08''
Weight of Single Tube
4409 lbs
Chuck Speed
40 rpm
Max Linkage Speed
196.85'/min
Maximum Acceleration
0.3G
Beveling Cutting
Optional
