USED 2022 ASTEC SRT11

2022 Astec Ranger SRT11 Tracked Trommel Screen — 285 Hours

Available on IronListing.com
Contact Garret for more information
📞 716-353-3676
✉️ [email protected]

IronListing is offering this 2022 Astec Ranger SRT11 Tracked Trommel Screen, Serial #225101, with only 285 hours. This low-hour unit is built for high-production screening applications and is equipped with a heavy-duty rotary screen, hydraulic conveyors, tracked mobility, and remote-control operation.

The Astec Ranger SRT11 is designed for contractors, aggregate producers, land clearing operations, recycling yards, mulch producers, compost processors, and material handling companies that need a compact yet capable trommel screen. With its tracked undercarriage, hydraulic tipping grizzly, variable-speed hydraulic drives, and multiple discharge conveyors, this machine is ready to move, set up, and go to work.

Key Specifications

Rotary Screen:
4’ 11” diameter x 13’ 9” long screen drum
1500mm x 4200mm
Variable speed hydraulic drive

Hopper:
3.8 cubic yard capacity
Standard grizzly with 8” openings
Hydraulic tipping grizzly
Hydraulic support legs

Belt Feeder:
36” nominal wide belt feeder
Variable speed hydraulic drive

Collection Conveyor:
48” nominal wide conveyor
Flat belt with hydraulic drive

Fines Side Conveyor:
30” nominal wide conveyor
Hydraulic drive

Overs Conveyor:
40” nominal front discharge conveyor
Variable speed hydraulic drive

Engine:
Deutz TCD2.2 L3 diesel engine
74 HP / 55 kW
Tier 4 Final

Fuel Tank:
26 gallon / 100 liter capacity

Tracks:
16” triple grouser track shoes

Operation:
Remote control operation

Machine Highlights

This Ranger SRT11 is a strong option for buyers needing a mobile trommel screen with low hours and practical production features. The hydraulic tipping grizzly helps manage oversized material before it enters the hopper, while the variable-speed feeder and screen drive allow the operator to fine-tune material flow. The machine’s tracked design makes it easier to maneuver around yards, jobsites, and production areas without needing to constantly reposition with additional equipment.

With only 285 hours, this 2022 Astec Ranger SRT11 gives buyers a late-model screening solution without waiting on new equipment lead times.

Contact

For pricing, availability, videos, or additional information, contact Garret today.

📞 716-353-3676
✉️ [email protected]
🌐 Available on IronListing.com
