*1342 Hours
X-Axis Travel: 30″ (560mm)
Y-Axis Travel: 20″ (508mm)
Z-Axis Travel: 20″ (508mm)
Traverse X & Y: 826″/min (21m/min)
Traverse Z: 710″/min (18m/min)
Axis Thrust X & Y: 1150 lbs (521 kg)
X & Y Peak Thrust: 3450 lbs (1564 kg)
Axis Thrust Z: 1700 lbs (771 kg)
Z Peak Thrust: 5100 lbs (2313 kg)
Spindle RPM: 8000 RPM
Spindle HP: 12 peak
Table (Working Area): 36″ x 18″ (838x457mm)
Machine Height: 100″ (2.54m)
Machine Width: 98″ (2.5m)
Machine Depth: 110″ (2.8m)
Machine Weight: 7,400 lbs (3356 kg
