XYZ EMX EMILL 2000

XYZ EMX EMILL 2000 CNC Turret Milling Machine – Reliable Performance for Precision Milling
The XYZ EMX EMILL 2000 is a capable and robust CNC turret milling machine designed to offer reliable performance in workshop and light-manufacturing environments. Known for its solid build quality and easy-to-operate control, this model balances flexibility with practicality — making it a great choice for both one-off jobs and smaller batch work.
Key Features & Highlights
Worktable & Travel: Fitted with a generous 1,270 × 254 mm table, the EMX EMILL 2000 provides ample workspace for a wide range of components and fixturing setups. Machining travel typically includes around 750 mm on the X-axis and 380 mm on the Y-axis, giving good flexibility for larger parts.
Spindle & Performance: Equipped with an R8 spindle taper and spindle speeds from approximately 60 – 4,200 rpm, this milling machine is well-suited to general milling, drilling and finishing tasks across materials like steels, aluminium and engineering plastics.
Control System: The machine usually features a ProtoTRAK EMX 2-axis control, known for user-friendly programming and reliable CNC operation — ideal for machinists of varied experience levels.
Construction & Accessories: Built to withstand workshop demands, the EMX EMILL 2000 typically includes essential accessories such as coolant, swarf tray and interlocked table guards, plus automatic lubrication — ensuring smooth operation and reduced downtime.
Why Choose the EMX EMILL 2000?
This model stands out for its balance of size, performance and usability. Whether you’re expanding your machining capacity, taking on more complex parts, or adding CNC capability to your shop floor, the EMX EMILL 2000 delivers dependable results with the support of established tooling and a trusted name in XYZ machine tools.
Note: Exact specifications, control options and machine condition can vary depending on the specific unit. Contact Blue Diamond Machine Tools Ltd for full details and confirmation of features before purchasing.

Year 2008
Proto TRAK EMX 2 -axis control
Table 1,270 x 254mm
Table travel 750 x 380mm
Quill travel 127mm
Spindle taper R8
Spindle speeds 60-4,200rpm
Spindle drive motor 2.2 kW (3 HP).
Manual operation/CNC cycles
Interlocked table guards
Automatic lubrication
Low volt light, Coolant
Swarf tray
Excellent condition
