Friction-free hydrostatic spindle bearing for precision grinding
Precision ball screw driven by AC digital servo motor
Mitsubishi PLC control with touch screen operation
High-grade Nichrome steel SNCM-220 wheel head
Table travels on one V, one flat guideway
Machine castings are fully ribbed and are made of dense, high-grade Meehanite cast iron
Tailstock center is capable of absorbing thermal expansion of work piece
Rough grinding, fine grinding and spark-out in one automated cycle.
Wheelhead retracts to park unload point after grinding cycle is completed
| Swing | 16.5" | 419.1 mm |
| Power | 5 hp | 3.7 kW |
| Workhead Power | 1.1 hp | 0.8 kW |
