• High precision cartridge type spindle is equipped with four pieces of Class 7 (P4) angular contact ball bearings plus a set of N-N needle roller bearings in front of spindle.
• Precision ball screws (C3 grade) on cross-feed and down-feed axes are directly coupled to Delta AC servo motors.
• Roller type linear guideway design for longitudinal movement of spindle head
• Automatic cycle + continuous flow lubrication system for guideways, ball screw and table.
| Table-W | 59.1" | 1,501.1 mm |
| Table-L | 118.1" | 2,999.7 mm |
| Power | 25 hp | 18.6 kW |
| Weight | 76,500 lbs. | 76,500 lbs. |
