Features
• Built-in 4th/5th Axis Trunnion Table
• Rigid solid box guideways incorporate a unique 4-slideway base construction for optimum rigidity
• High speed rapids of 1417ipm (X, Y & Z) boosts work throughput
• High speed 15,000rpm, 35HP, Dual Contact Spindle
• Standard base wash system, internal chip augers and scraper type chip conveyor
• Plumbed for coolant thru the spindle (220psi/1000psi option)
• Affordably priced and feature packed!
| X | 31.5" | 800.1 mm |
| Y | 24.02" | 610.11 mm |
| Z | 20.08" | 510.03 mm |
| # Axis | 5 | 5 |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 30 | 30 |
| Taper | NST No. 40 | NST No. 40 |
